Description

TECHNICAL DATA

• Length of shell with fuze: 626 mm

• Mass of mortar shell with fuze: 12,600 g

• Explosive charge: Thermobaric

• Mass of explosive charge: 2400 g

• Fuze: Impact, superquick, delay action UTU, M93 P1

• Muzzle safety at lowest initial velocity: 50 m

• Shell composition: Includes ignition cartridge and increment charges

• Safe operational temperature range: –30°C to +50°C

• Safety: High safety during transportation, handling, and parachuting

---

BALLISTIC DATA

When fired from a 120 mm mortar (barrel length: 1500 mm):

• Maximum range: 6555 m

• Maximum mean operating pressure in mortar: < 922 bars

Compatible with smooth bore mortar launchers.

---

PACKING

• Packing configuration: 1 complete shell per carton

• Cartons per wooden case: 2

• Wooden case dimensions: 738 × 352 × 211 mm

• Gross weight of wooden case: 41.5 kg

• Volume of wooden case: 0.055 m³

• UN Number: 0321

• Hazard class: 1.2E

---
