Description
| Caliber | 40mm |
| Number of grooves in the barrel | 6 |
| Step twisting grooves | 1groove/1200mm (right) |
| Barrel length | 300mm |
| Drum Capacity | 6 grenades |
| The Length of drum | 140mm |
| Type of fire | Double action |
| Maximum velocity | 78±5m/s |
| Weight without ammunition | 5,9kg |
| Length with stock folded | 725mm |
| Length with fully extended stock | 800mm |
| Height | 360mm |
| Width | 160mm |
| Ammunition | 40x46mm (NATO-standard) |
| Rate of fire | ≥ 12 grenade/min |
| Sight | Reflex sight |
| Maximum range | 375±30m |
| Mechanical sight, range: | 50 m to 300 m Divisions per 50m 300 m to 375 m Divisions per 25m, |
| Working temper. range | -30°C do +55°C |
Description
Grenade launchers are intended for execution of police duties such as suppression of mass demonstrations and riots. Uses ammunition caliber 37mm/38mm with non-lethal effects (grenades with one and three-piece rubber bullets, tear gas grenades, smoke or illuminating filling, shock grenades). They are used at maximum distances of up to 150m.
